频率范围 38 Hz - 20 kHz

交叉 Amp 3.2 kHz

Maximum SPL (1m) 110 dB

最大输入电平 Unbalanced: +6 dBV;Balanced: +20.3 dBV

输入连接器 1 x RCA (unbalanced);1 x TRS or 1 x XLR (balanced)

Input Sensitivity (-10 dBV input) 92 dB @ 1m

HF DRIVER SIZE 25 mm

LF DRIVER SIZE 5.5” (165.1 mm)

HF DRIVER POWER AMP 70 W Class AB

LF DRIVER POWER AMP 70 W Class AB

HF TRIM CONTROL +1 dB, 0 dB,-1 dB, -2 dB @ 10 kHz

LF Trim Control +2 dB, 0,-1 dB, -2 dB @ 60 Hz

AC INPUT VOLTAGE 220 VAC ±10%, 50-60 Hz

THD+N < 0.2%

噪音 < 0.3 mV

S/N > 95 dB

ENCLOSURE CONSTRUCTION 15 mm MDF

ENCLOSURE FINISH PVC

BAFFLE CONSTRUCTION ABS + PC

尺寸（高 x 宽 x 厚） 359 x 215 x 263.5 mm

重量 4.78 Kg / piece

DISPLAY CARTON (H x W x D) 320 x 284 x 442 mm

SHIPPING CARTON (H x W x D) 338 x 302 x 460 mm

运输重量

6.08 Kg / piece

Unit(s) Per Package 1 piece
